What is this machine used for?
What is the Tiezheng VTF640-2?
The Tiezheng VTF640-2 is a dual-spindle drilling and tapping center with two independent spindles that can machine simultaneously. It combines a 1300 × 420 mm worktable, 700/400/350 mm X/Y/Z travel and 600 mm spindle-center spacing. The standard spindle speed is 20,000 rpm and the standard tool-magazine capacity is 21 tools. Fixtures and tooling are selected for the part geometry and machining sequence.
How can the dual-spindle layout fit a production process?
Two independent spindles can machine simultaneously. Match fixture positions, spindle-center spacing and tool access to the part and process sequence. Actual cycle time depends on the operations, tooling, material and loading method.
Which VTF640-2 specifications can buyers compare?
The specification table covers the worktable and travel, spindle, feeds, guideways, accuracy, tool magazine, utilities, dimensions and chip removal. Standard and optional spindle speeds are listed separately.
What are the table size and axis travels?
The worktable is 1300 × 420 mm with a maximum load of 350 kg. X/Y/Z-axis travels are 700/400/350 mm.
What is the spindle-center spacing?
The dual-spindle center distance is 600 mm. Spindle-nose-to-table distance ranges from 100 to 450 mm.
Which spindle speeds and tool magazine are listed?
Standard spindle speed is 20,000 rpm; 12,000 and 18,000 rpm options are also listed. The standard clamp-arm tool magazine holds 21 tools.
What are the machine dimensions and weight?
Machine length is 1800 mm, width is 1600 mm and maximum height is 2500 mm. Machine weight is 3600 kg.
How do I request a VTF640-2 quotation?
Send your part drawing, material, dimensions, critical tolerances, required operations, annual volume and target cycle time. Include workholding or automation needs, electrical standard and destination country. The quotation and technical agreement define the supplied configuration and acceptance requirements.
